Підсилювач звуку 2x120W XH-A105 Bluetooth 5.0 TDA7498 TF AUX

Високоякісний підсилювач XH-A105 з Bluetooth 5.0 на чипі TDA7498

Бездротовий цифровий підсилювач потужності Стерео Аудіо дошка 2x100W AMP amplificador Підтримка TF Card AUX.

Живлення 12-24В

Мікросхема: TDA7498
Напруга живлення (однополярної): 12-24 В
Максимальна вихідна потужність: 2 Х 120 вт
Частотний діапазон: 20 Гц-20 кГц
ККД:більше 90%
Максимальний вихідний струм: 3 А
Розміри 92х85х20 мм

Product Feature

TDA7498 Digital amplifier board Support bluetooth 5.0 high speed transmission, APE, FLAC, MP3, WAV, WMA, such as music format, the music format can be decoded the mainstream market, as long as the mobile phone can play this bluetooth can, does not affect the distance won't be caton.

Product specification

TDA7498 bluetooth power amplifier board, using the original installation import power amplifier chip, has the high fidelity stereo sound quality; Support bluetooth, TIF card, AUX input audio power amplifier configuration bluetooth 5.0 high speed transmission, support the APE, FLAC, MP3, WAV, WMA music formats, such as the music format can be decoded the mainstream market, as long as, on the mobile phone can play this bluetooth can, does not affect the distance won't be caton. Bluetooth effective transmission distance of 20 meters unimpeded connection, but according to the personal phone bluetooth configuration, signal strength is different, the transmission distance will be a gap. Power amplifier input power for DC12-30 v, have double sound channel output, output impedance is 4-82, maximum power 100 w2; Onboard volume potentiometer, are free to adjust the volume.

Basic parameters:

1. Working mode: class D 2.Audio input: support bluetooth, TIF card, AUX analog signal 3. Rated output power: 100W+100W 4. Frequency response: 20Hz to 20KHz 5. Working voltage: DC12V to DC30V 6. Recommended power voltage: DC19V 7. Fit speaker parameters: 4-8 ohms 8. size: 92*85*18MM 9.Net weight: about 83g

HIFIDIY LIVE XH-A105 Bluetooth 5.0 TDA7498 digital amplifier board 2x100W speaker Stereo Audio AMP Module Support TF Card AUX
